2019 Sennebogen 840M | E-Series Material Handler
This 2019 Sennebogen 840M is a purpose-built powerhouse designed for high-volume material handling in scrap processing, port operations, and recycling facilities. With 9,600 operating hours, this E-Series machine offers a proven track record of reliability and efficiency, powered by a robust Cummins QSL9 engine delivering 305 HP.

Key Performance Specs:
Boom Configuration: K20 Equipment (approx. 66 ft / 20m reach) for maximum coverage.

Undercarriage: 4-point outrigger mobile undercarriage for superior stability during heavy lifts.

Operator Comfort: Elevating Maxcab with panoramic visibility and ergonomic controls for 360° safety.

Efficiency: Features Eco Mode and automated idle/stop systems to reduce fuel consumption and wear.

Why Choose the Sennebogen 840M?
The 840M is the “big brother” to the 835, offering a larger undercarriage and higher load capacities for heavier materials. Whether you’re unloading ships or feeding a shredder, the K20 reach provides the versatility needed for complex job sites. This 2019 model represents an excellent value for operations looking to upgrade their fleet with a modern, high-capacity handler without the new-machine lead times.

Original Factory Specs

Engine
Cummins L9 diesel engine with direct injection, water cooled (Tier 4f emission)
Engine output 310 HP (231 kW) @ 2,000 rpm
Turbo intercooler direct driven
Water cooler hydraulically driven, reversible
Automatic idle-stop control and eco-mode for diesel engine

Hydraulic System
Computer free, state-of-the-art load-sensing with flow-on-demand control
Hydraulic cooler hydraulically driven reversible
Hydro-Clean filtration system with water absorption and contamination indicator
Automatic central lubrication for equipment, slewing ring raceway

Upper Carriage & Swing System
Torsion free, precisely machined upper carriage frame
High torque axial piston swing motor
Large dimensioned, external teeth swing bearing with removable protection cover
Automatic central lubrication system for upper carriage
Counter rotation of cooler ventilator to blow out the cooler with automatic control
Manual pinion lubrication system for swing bearing
360° protection for gear rim.
Handrail on top of upper carriage (Installed prior to shipping)
Fire extinguisher set (1x cab, 1x storage compartment) – brackets installed, extinguisher shipped separate
Lighting system 1 (mobile machine):
2 pcs. H4 headlights mounted in the uppercarriage-frame on the front side left and right, 2 rear lights and 2 lights integrated in the left front side of the cab roof. LED headlight with magnetic fixing support and 5m of cable for flexible connection in maintenance area.

Operator’s Cab “maXCab”
Hydraulic elevating cab system “E270″ (elevation: 8’8″)
Catwalk with handrail beside cab (To be installed on site)
maXCab with sliding door and door window as sliding window, sunshade, floor mat
Front window to fold upwards
Wiper/ washer system for front window
Skylight
Front window & Skylight protection guard (Installed prior to shipping)
Automatic climate control with AC, heater and defroster
AM/FM radio with MP3/Bluetooth
SENCON visual and acoustic diagnostic system for monitoring all essential machine functions
Air suspended and adjustable operator’s seat incl. armrests, seat heater, headrest, seat belt
Camera system – base package with 2 cameras
– Includes 1 color monitor 7”, monitor with 4-way split, up to 4 cameras expandable, 2 cameras with 115° field viewing angle
– rear view camera
– right side of the machine
2 lights integrated in the front of the roof
1 pc. LED headlight mounted on the cab roof right side heading backwards
Joystick steering

Working Equipment
K20 – reach 65.6′ / purpose-built material handling working equipment
SCV boom and stick cylinder
Boom & Stick cylinders equipped with safety check valves and end position damping
End position shut off for boom up/down and stick in/out function.
Attachment open/close and rotate hydraulic circuits and lines installed up to the end of the stick (installed prior to shipping)
Quick change couplers (bolted type) with counter pieces for grab open/close and grab rotating
Lighting system 3 LED equipment: 1 pc. LED headlight mounted on the compact boom down side and 2 pcs
LED headlights mounted on both sides of the stick in upper position

Under Carriage
Rubber tired under carriage MP42E with 4-point outriggers
Individual control of 4-point outriggers
Automatic unlock of oscillating axle if upper carriage in longitudinal direction to under carriage
Solid rubber tires 12.00-24 (8 units) inclusive intermediate protection ring
Steering via joy stick, front wheel steering
All wheel drive via two variable hydraulic motors direct mounted on each axle
Protection guard for hydraulic drive motors (Installed prior to shipping)
2-circuit servo brake system with additional safety brake
Centralized lubrication points (front & rear) for lubrication of under carriage components
Audible travel alarm while driving machine (forward & backward)
Toolbox w/ basic tools, stick pin, grease gun, wheel chock, green & gray touch up paint located in under carriage tool box

Magnet System (Installed prior to shipping)
25 kW Baldor generator, hydraulic driven with Hubbell controller
Plug in front of stick to hook up magnet, magnet connection cable in under carriage tool box
Magnet suspension link (Will be shipped w/ the machine)
